A BSP (British Standard Pipe) Male Stud onnector is a vital component in fluid handling systems, especially in industries where secure and leak-proof connections are essential. The BSP standard, widely adopted in the United Kingdom and various parts of the world, ensures uniformity and compatibility in threaded pipes and fittings. The male stud connector, conforming to BSP specifications, plays a crucial role in joining pipes and other fluid-carrying elements securely.
The BSP male stud connector is characterized by its threaded design, which allows for a tight and reliable connection between pipes, valves, or other components in a fluid system. The threads on both ends of the connector are precisely machined to align with the corresponding threads on the connected components, ensuring a seamless fit.
One of the key advantages of a BPS male stud connector is its versatility. It can be employed across a wide range of industries and applications, from industrial processes to hydraulic systems, and even in domestic plumbing. The design and engineering of the male stud connector prioritize durability, efficiency, and ease of installation, making it a preferred choice for professionals seeking dependable fluid connections.
PART NO. |
Thread |
WINNER PART NO. |
Description |
|
1 |
2 |
|||
GE 06L-1/8"BSP |
M12×1.5 |
G1/8"-19 |
1CG-12-02 |
|
GE 08L-1/4"BSP |
M14×1.5 |
G1/4"-19 |
1CG-14-04 |
|
GE 10L-1/4"BSP |
M16×1.5 |
G1/4" 19 |
1CG-16-04 |
|
GE 12L-1/4"BSP |
M18×1.5 |
G1/4"-19 |
1CG-18-04 |
|
GE 08L-3/8"BSP |
M14×1.5 |
G3/8"-19 |
1CG-14-06 |
|
GE 10L-3/8"BSP |
M16×1.5 |
G3/8"-19 |
1CG-16-06 |
|
GE 12L-3/8"BSP |
M18×1.5 |
G3/8“-19 |
1CG-18-06 |
|
GE 15L-3/8"BSP |
M22×1.5 |
G3/8"-19 |
1CG-22-06 |
|
GE 12L-1/2"BSP |
M18×1.5 |
G1/2"-14 |
1CG-18-08 |
|
GE 15L-1/2"BSP |
M22×1.5 |
G1/2"-14 |
1CG-22-08 |
|
GE 18L-1/2"BSP |
M26×1.5 |
G1/2"-14 |
1CG-26-08 |
|
GE 18L-3/4"BSP |
M26×1.5 |
G3/4"-14 |
1CG-26-12 |
|
GE 22L-3/4"BSP |
M30×2.0 |
G3/4"-14 |
1CG-30-12 |
|
GE 22L-1"BSP |
M30×2.0 |
G1"-11 |
1CG-30-16 |
|
GE 28L-1"BSP |
M36×2.0 |
G1"-11 |
1CG-36-16 |
|
GE 35L-1"BSP |
M45×2.0 |
G1"-11 |
1CG-45-16 |
|
GE 35L-1.1/4"BSP |
M45×2.0 |
G1.1/4"-11 |
1CG-45-20 |
|
GE 42L-1.1/2"BSP |
M52×2.0 |
G1.1/2"-11 |
1CG-52-24 |
|
GE 06S-1/4"BSP |
M14×1.5 |
G1/4"-19 |
1DG-14-04 |
|
GE 08S-1/4"BSP |
M16×1.5 |
G1/4"-19 |
1DG-16-04 |
|
GE 10S-1/4"BSP |
M18×1.5 |
G1/4" 19 |
1DG-18-04 |
|
GE 10S-3/8"BSP |
M18×1.5 |
G3/8"-19 |
1DG-18-06 |
|
GE 12S-3/8"BSP |
M20×1.5 |
G3/8"-19 |
1DG-20-06 |
|
GE 14S-3/8"BSP |
M22×1.5 |
G3/8“-19 |
1DG-22-06 |
|
GE 14S-1/2'BSP |
M22×1.5 |
G1/2"-14 |
1DG-22-08 |
|
GE 16S-1/2"BSP |
M24×1.5 |
G1/2"-14 |
1DG-24-08 |
|
GE 20S-1/2"BSP |
M30×2.0 |
G1/2"-14 |
1DG-30-08 |
|
GE 20S-3/4"BSP |
M30×2.0 |
G3/4"-14 |
1DG-30-12 |
|
GE 25S-3/4"BSP |
M36×2.0 |
G3/4"-14 |
1DG-36-12 |
|
GE 25S-1"BSP |
M36×2.0 |
G1"-11 |
1DG-36-16 |
|
GE 30S-1"BSP |
M42×2.0 |
G1"-11 |
1DG-42-16 |
|
GE 30S-1.1/4"BSP |
M42×2.0 |
G1.1/4"-11 |
1DG-42-20 |
|
GE 38S-1.1/2"BSP |
M52×2.0 |
G1.1/2"-11 |
1DG-52-24 |
Note: The above code includes adapters, if you need a complete set, please add "RN", such as "GE 06L-1/8"BSP/RN".
