A bulkhead union is a crucial component in the realm of piping systems and fluid conveyance, serving as a reliable and efficient connector. Its fundamental design and purpose lie in seamlessly joining two pipes or tubes while maintaining a leak-proof and secure connection, especially when crossing through a barrier or wall.
This specialized fitting ensures fluid continuity, structural integrity, and safety within diverse industrial, commercial, and residential applications. By enabling a secure and sealed connection through walls or partitions, bulkhead unions facilitate the efficient transfer of liquids, gases, or other substances across distinct spaces or units.
In essence, a bulkhead union serves as a bridge, allowing fluid transmission between separated areas without compromising the system's overall performance. Its design is meticulously engineered to resist pressure, temperature variations, and external forces, ensuring a robust and enduring connection. Whether in hydraulic systems, plumbing networks, or industrial pipelines, the bulkhead union plays a vital role in maintaining the integrity and functionality of fluid conveyance systems.
PART NO. |
Thread |
WINNER PART NO. |
Description |
|
1 |
2 |
|||
SV 06L |
M12×1.5 |
|
6C-12 |
![]()
|
SV 08L |
M14×1.5 |
|
6C-14 |
|
SV 10L |
M16×1.5 |
|
6C-16 |
|
SV 12L |
M18×1.5 |
|
6C-18 |
|
SV 15L |
M22×1.5 |
|
6C-22 |
|
SV 18L |
M26×1.5 |
|
6C-26 |
|
SV 22L |
M30×2.0 |
|
6C-30 |
|
SV 28L |
M36×2.0 |
|
6C-36 |
|
SV 35L |
M45×2.0 |
|
6C-45 |
|
SV 42L |
M52×2.0 |
|
6C-52 |
|
SV 06S |
M14×1.5 |
|
6D-14 |
|
SV 08S |
M16×1.5 |
|
6D-16 |
|
SV 10S |
M18×1.5 |
|
6D-18 |
|
SV 12S |
M20×1.5 |
|
6D-20 |
|
SV 14S |
M22×1.5 |
|
6D-22 |
|
SV 16S |
M24×1.5 |
|
6D-24 |
|
SV 20S |
M30×2.0 |
|
6D-30 |
|
SV 25S |
M36×2.0 |
|
6D-36 |
|
SV 30S |
M42×2.0 |
|
6D-42 |
|
SV 38S |
M52×2.0 |
|
6D-52 |
Note: The above code includes adapters, if you need a complete set, please add "RN", such as "SV-06L/RN".
