An elbow BSP (British Standard Pipe) male fitting with a 60° seat is a critical component in fluid and gas handling systems, offering a versatile and reliable solution for various applications. The BSP threading standard is widely recognized and adopted in industries worldwide, known for its precision and efficiency in creating leak-proof connections.
The BSP male designation indicates that this fitting has external threads, allowing it to be securely threaded into a corresponding female BSP port or component.
The 60° seat in this fitting refers to the cone angle of the sealing surface, ensuring a tight and efficient seal when connected to a matching BSP female counterpart. This design is crucial for preventing leaks and maintaining the integrity of the fluid or gas flow within the system.
Applications for this elbow BSP male 60° seat fitting are diverse, ranging from hydraulic systems, pneumatic systems, plumbing, agriculture, and industrial machinery. Its design and functionality make it an essential component for optimizing fluid flow and ensuring system reliability in various operational environments.
PART NO. |
Thread |
WINNER PART NO. |
Description |
|
1 |
2 |
|||
A5BB-02-02 |
G1/8"×28 |
G1/8"×28 |
1B9-02 |
|
A5BB-04-04 |
G1/4"×19 |
G1/4"×19 |
1B9-04 |
|
A5BB-06-06 |
G3/8"×19 |
G3/8"×19 |
1B9-06 |
|
A5BB-08-08 |
G1/2"×14 |
G1/2"×14 |
1B9-08 |
|
A5BB-10-10 |
G5/8"×14 |
G5/8"×14 |
1B9-10 |
|
A5BB-12-12 |
G3/4"×14 |
G3/4"×14 |
1B9-12 |
|
A5BB-16-16 |
G1"×11 |
G1"×11 |
1B9-16 |
|
A5BB-20-20 |
G1.1/4"×11 |
G1.1/4"×11 |
1B9-20 |
|
A5BB-24-24 |
G1.1/2"×11 |
G1.1/2"×11 |
1B9-24 |
|
A5BB-32-32 |
G2"×11 |
G2"×11 |
1B9-32 |
