The JIC (Joint Industry Council) Female 37° Cone Seat fitting, conforming to SAE J514 standards, is an essential component in hydraulic and fluid systems, well-regarded for its reliability and universal compatibility. This fitting is meticulously engineered to meet the stringent requirements of SAE J514, ensuring its adherence to standardized dimensions and performance expectations.
This fitting employs a 37-degree cone seat design, which is a common standard in hydraulic applications. This precise cone design ensures a secure and leak-resistant connection when mated with a compatible male JIC fitting. The 37-degree angle provides a reliable seal even under high-pressure conditions, making it ideal for a wide range of hydraulic applications.
Complies with the SAE J514 standard and highlights the quality and reliability of the fitting, making it a better choice for professionals in hydraulic and fluid systems. Its universal compatibility with other JIC components and adherence to standardized dimensions ensure seamless integration into hydraulic systems, whether in manufacturing, construction, or industrial settings.
|
Part No. |
Thread E |
WINNER PART NO. |
Description |
|
05-07-04 |
7/16"×20 |
26711-04-04 |
|
|
05-07-05 |
7/16"×20 |
26711-04-05 |
|
|
05-04-06 |
7/16"×20 |
26711-04-06 |
|
|
05-08-04 |
1/2"×20 |
26711-05-04 |
|
|
05-08-05 |
1/2"×20 |
26711-05-05 |
|
|
05-09-04 |
9/16"×18 |
26711-06-04 |
|
|
05-09-05 |
9/16"×18 |
26711-06-05 |
|
|
05-09-06 |
9/16"×18 |
26711-06-06 |
|
|
05-09-08 |
9/16"×18 |
26711-06-08 |
|
|
05-12-06 |
3/4"×16 |
26711-08-06 |
|
|
05-12-08 |
3/4"×16 |
26711-08-08 |
|
|
05-14-08 |
7/8"×14 |
26711-10-08 |
|
|
05-14-10 |
7/8"×14 |
26711-10-10 |
|
|
05-17-08 |
1.1/16"×12 |
26711-12-08 |
|
|
05-17-10 |
1.1/16"×12 |
26711-12-10 |
|
|
05-17-12 |
1.1/16"×12 |
26711-12-12 |
|
|
05-19-12 |
1.3/16"×12 |
26711-14-12 |
|
|
05-21-12 |
1.5/16"×12 |
26711-16-12 |
|
|
05-21-16 |
1.5/16"×12 |
26711-16-16 |
|
|
05-26-16 |
1.5/8"×12 |
26711-20-16 |
|
|
05-26-20 |
1.5/8"×12 |
26711-20-20 |
|
|
05-30-20 |
1.7/8"×12 |
26711-24-20 |
|
|
05-30-24 |
1.7/8"×12 |
26711-24-24 |
|
|
05-40-32 |
2/1/2"×12 |
26711-32-32 |
