Designed to strict ISO 12151-1/SAE J516 standards, the ORFS Female Flat Seat Double Hex stands out as a compelling solution for hydraulic and fluid connection systems.The ORFS, short for O-Ring Face Seal, is a widely recognized and trusted design in the fluid power industry, renowned for its great sealing capabilities and reliability. This particular fitting combines the ORFS design with a double hex feature, offering enhanced installation convenience and security.
Manufactured using top-quality materials, this fitting is engineered for durability and longevity, ensuring it can withstand the rigors of demanding applications. Its ISO 12151-1/SAE J516 compliance certifies its adherence to internationally recognized standards, making it a versatile choice for hydraulic systems across the globe.
The standout feature of this fitting is its double hex design, which provides two wrench flats for installation. This not only simplifies the fitting process but also enhances the torque application, ensuring a tight and reliable connection. When paired with a compatible male ORFS fitting, the integrated O-ring face seal and double hex of the female fitting guarantee a leak-free and secure connection, contributing to the safety and efficiency of hydraulic systems.
Part No. |
Thread E |
WINNER PART NO. |
Description |
702-04-04 DH |
9/16"×18 |
24211D-04-04 |
|
702-06-06 DH |
11/16"×16 |
24211D-06-06 |
|
702-08-08 DH |
13/16"×16 |
24211D-08-08 |
|
702-10-10 DH |
1"×14 |
24211D-10-10 |
|
702-12-10 DH |
1.3/16"×12 |
24211D-12-10 |
|
702-12-12 DH |
1.3/16"×12 |
24211D-12-12 |
|
702-16-16 DH |
1.7/16"×12 |
24211D-16-16 |
|
702-20-20 DH |
1.11/16"×12 |
24211D-20-20 |
